SPIROMETRY SPECIFICATIONS:
– Power supply: Rechargeable battery
– Autonomy: approx. 10 hours
– Temperature sensor: semiconductor (0-45°C)
– Flow sensor: bi-directional digital turbine
– Flow range: ±16L/s
– Volume accuracy: ±3% or 50mL
– Flow accuracy: ±5% or 200mL/s
– Dynamic resistance: <0.5 cm H2O/L/s
– Connectivity: USB 2.0, Bluetooth® 2.1
– Display: 7” colour touch screen LCD, 800×480 resolution
– Mouthpieces: Ø 30 mm (1.18 inch)
– Dimensions: 220x210x51 mm (8,66×8,26×2“)
– Weight: 1450 g (battery pack included) (3,1lb)
– Electrical protection: Class II
– Norms: Electrical safety standard EN 60601-1
– Electromagnetic compatibility EN 60601-1-2
– Spirometry Parameters: FVC, FEV1, FEV1/FVC, FEV1/VC, PEF, FEF25, FEF50, FEF75, FEF25-75, FEF75-85, Lung Age, Extrapolated Volume, FET, Time to PEF, FEV0.5, EV0.5/FVC, FEV0.75, FEV0.75/FVC, FEV2, FEV2/FVC, FEV3, FEV3/FVC, FEV6, FEV1/ FEV6, FEV1/PEF, FEV1/FEV0.5, FIVC, FIV1, FIV1/FIVC, PIF, FIF25, FIF50, FIF75, FEF50/FIF50, VC, IVC, IC, ERV, IRV, Rf, VE, VT, tI, tE, VT/tI, tE/tTOT, MVV (measured), MVV (calculated).
OXIMETRY SPECIFICATIONS:
– SpO2 range: 0-99%
– SpO2 accuracy: ± 2% between 70-99% SpO2
– Pulse Rate range: 18-300 BPM
– Pulse Rate accuracy: ± 2BPM or 2% whichever is greater
– Memory capacity: up to 500 hours oximetry
– Oximetry parameters: %SpO2 and Pulse Rate (Min, Max, Average), Test duration, Total SpO2 Events, T90% (SpO2 time =89%), T89% (SpO2 time =88%), T40 (Bradycardia duration with Pulse Rate <40 BPM), T120 (Tachycardia duration with Pulse Rate >120 BPM).
WINSPIRO PRO® SOFTWARE REQUIREMENTS:
Windows 2000, Xp, Vista (32/64 bit), 7 (32/64 bit), 8 and 8.1 (32/64 bit), 10 (32/64 bit). RAM 512 MB
